The Gigabit SFP Transceivers use the Small Form-factor Pluggable (SFP) design.They provide the necessary signal amplification for data to be transmitted to the network cable from the port, and vice versa. The SFP form factor is advantageous because it is smaller than other form factors such as Xenpak, X2, and 10G XFP, ensuring lower costs, lower power disruption, and higher port density.
All D-Link transceivers are hot pluggable. You can connect a transceiver while the system is powered on without causing any issues and easily swap one for another without having to reboot the switch each time. This permits modules to be added or removed without interrupting the network, facilitating maintenance and greatly reducing downtime.
Applications of the DEM-300 Series fiber transceivers include distributed multiprocessing, Gigabit switch cascading, high-speed I/O file transfer, bus extension application, and channel extender/data storage. This versatility is invaluable for an expanding network and helps the infrastructure grow with the business.
| General features |
|
|---|---|
| Standard | IEEE 802.3z 1000Base-LX |
| Wavelength | 1310 nm |
| Data Rate |
1.25 Gbps |
| Connector | Duplex LC |
| Fiber Type | 9/125 um Single-mode Fiber |
| Maximum Fiber Cable Length | 10 km |
| Transmit Power Range | -3 to -9 dBm |
| Receive Power Range | -3 to -22 dBm |
| Sensitivity | -22 dBm |
| Physical Parameters |
|
| Power Support | 3.3 V |
| Supply Current | 220 mA |
| Temperature |
Operating: 0° to 70°C Storage: -40° to 85°C |
| Humidity |
Operating: 0% to 85% Storage: 0% to 85% |
| Dimensions | 56 mm x 13.7 mm x 8.5 mm |
