10埠 L2 Gigabit Smart Managed 智慧網管 PoE交換器
DGS-1210-10P
- Product Status (Fx v13): Live
- 8埠 10/100/1000Mbps(1Gbps) base-T PoE
- 2埠 100/1000Mbps SFP光纖上行埠
- 支援專屬Surveillance監控模式，並具Auto IGMP功能
- PoE供電支援802.3af/at，總供電輸出可達65W
- 無風扇靜音設計，金屬外殼散熱良好
- CLI 指令 + 完整L2網管 + L3基本功能配置
- 多種管理方式、網路安全設定功能
- 支援19吋機架安裝
Where to buy
Comprehensive Security Features to Protect Your Network
D-Link's innovative Safeguard Engine protects switches against traffic flooding and virus attacks. 802.11X port-based authentication allows the network to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and helps to protect the internal IT network.
產品規格
|
Interfaces
|
8 x 10/100/1000BASE-T PoE ports 2 x SFP ports |
|---|---|
|
Switch Capacity
|
20 Gbps |
|
Max. Packet Forwarding Rate
|
14.88 Mpps |
|
Dimensions
|
280 x 126 x 44 mm |
|
Weight
|
0.95 kg |
|
Temperature
|
Operating: -5 to 50° C (23 to 122° F) Storage: -20 - 70 ˚C |
|
Operating Altitude
|
1500 m |
|
Max Power Consumption
|
89.1 W/100 V, 80.6 W/240 V(PoE on) 7.6 W/100 V, 7.5 W/240 V(PoE off) |
|
Standby Power Consumption
|
2.5 W/100V 2.5 W/240V |
|
Humidity
|
Operating: 0% - 95% RH Storage: 0% - 95% RH |
|
Maximum Heat Dissipation
|
279.59 BTU/hr (100V) 275.04 BTU/hr (240V) |
|
MTBF
|
729,258 hours |
|
Power Input
|
100 to 240 V AC |
|
CPU Speed
|
500MHz |
|
DRAM Size
|
DDR3 128MB |
|
Flash Memory Size
|
32 MB |
|
Packet Buffer Size
|
4.1Mbits |
|
FAN
|
Fanless |
|
Acoustic
|
0 dB |
|
PoE Budget
|
65 W |
|
實際效能可能因設定、線纜、溫度、網路配置、介面、設備相容性、環境和現場條件以及其他類似因素而有所不同。有關功率、訊號或處理速度、訊號範圍或距離、資料加密、儲存容量、顯示特性或其他效能指標的說明均基於業界標準得出的最佳條件，僅供參考。規格如有變更，恕不另行通知。 |
|
