The D-Link DGS-1510 Series is the latest generation of Smart Managed switches with 10G SFP+ fibre ports for physical stacking or uplinks. The combination of high bandwidth connections, an Industry Standard CLI, and PoE options make the DGS-1510 Series ideal for Small-Medium Enterprise environments.
The DGS-1510 family has advanced network management options, accessible via Industry Standard CLI, Serial Port Console or the Web-based UI, that equip your business with network capabilities such as VLANs, multiple spanning tree protocol (MSTP), link aggregation (LACP), static routing, multiple firmware images,and multiple configuration files.
Create a physical stack of up to 6 units in a fault‑tolerant ring or linear topology using Direct Attach Cables or any compatible SFP+ transceivers for a total of 288 Gigabit ports. The remaining uplink ports can be used for other functions, offering 10G connectivity to core networks and servers.1
With powerful security features like IGMP snooping, access control lists, port security, and the unique D-Link Safeguard Engine that protects your network against malicious denial-of-service attacks from broadcast, multicast and unicast flooding, the DGS-1510 family is a versatile solution for enterprise network environments.
Choose between 193W and 370W power budget options. Or utilise a total of 740W when adding a redundant power supply to the DGS-1510-52XMP.
The DGS-1510 Series supports D-View 8, an intelligent management platform that allows for centralized management of the core network. This extensive toolset enables administrators to easily set up and remotely manage their networks, greatly reducing switch deployment time.
D-Link Green technology enables the DGS-1510 series to save power without sacrificing performance. The entire series of switches feature a smart fan that adjusts fan-speed and only powers on above a certain temperature. With advanced silicon technology, the DGS-1510 series saves up to 73% of energy compared to normal switches.
| Product |  DGS-1510-28XMP |  DGS-1510-52XMP |
|---|---|---|
| Interfaces |
|
|
| Performance | ||
| Switch Capacity | 128 Gbps | 176 Gbps |
| Max. Packet Forwarding Rate | 95.24 Mpps | 130.95 Mpps |
| PoE | ||
| PoE Budget | 370 W | 370 W (without RPS); Max. 740 W (with RPS, only supports DPS-700) |
| Technical Specification | ||
| Maximun Heat Dissipation | 1,487.78 BTU/hr | 1,660.33 BTU/hr |
| Maximum Power Consuption | 436.3 W (PoE on) 38.4 W (PoE off) | 486.9 W (PoE on) 58.8 W (PoE off) |
| MTBF | 274,796 hours | 303,027 hours |
|
Interfaces
|
4 x 10G SFP+ ports 24 x 10/100/1000BASE-T PoE ports |
|---|---|
|
Switch Capacity
|
128 Gbps |
|
PoE Power Budget
|
370 W |
|
Max. Packet Forwarding Rate
|
95.24 Mpps |
|
Maximum Heat Dissipation
|
1,487.78 BTU/hr |
|
Max Power Consumption
|
436.3 W (PoE on) 38.4 W (PoE off) |
|
MTBF
|
274,796 hours |
|
Power Input
|
AC:100 ~ 240 V |
|
CPU Speed
|
400MHz |
|
FAN
|
2 DC Fans |
|
Flash Memory Size
|
32 MB |
|
DRAM Size
|
256MB |
|
Humidity
|
Operating: 0% - 95% RH Storage: 0% - 95% RH |
|
Temperature
|
Operating: -5 to 50° C (23 to 122° F) Storage -20 - 70°C |
|
Dimensions
|
440 x 308.5 x 44mm |
|
Weight
|
4.25 kg |
|
Packet Buffer Size
|
1.5MB |
|
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice. |
|
